上海田枫15平方冷冻干燥机技术规格及配置
TF-FZG-15（15平方）
General Detail 总述 | ||
Sr. No. | Description 冷冻干燥机描述 | Specifications 规格 |
1 | Mode 冷冻干燥机型号 | TF-FZG-15 |
2 | area (sq. m) 冷冻干燥机面积 | 15.74 |
3 | Processing capacity(approx.) 冷冻干燥机处理量（大约） | 150KG |
4 | Maximum ice capacity 冷冻干燥机最大捕冰力 | 300kg |
5 | Control 冷冻干燥机控制方式 | Microprocessor 微机处理 |
6 | Dimension of unit (approx.) (L × W × H) (mm) 冷冻干燥机外型尺寸（大约）（长×宽×高） | 6700×1800×3500 (Final dimension based on design) （以最终设计尺寸为准） |
7 | Weight (approx.) 冷冻干燥机重量（大约） | 7,000kg |
8 | Chamber type/Material 冷冻干燥机冻干箱外型 | Cylindrical/SUS 304 圆筒体/SUS 304 |
9 | Shelves Temperature range 冷冻干燥机板层温度范围 | -45℃ to + 80℃ |
10 | Condenser Final temperature 冷冻干燥机冷凝器极限温度 | -60℃ |
11 | Compressor 冷冻干燥机压缩机 | BITZER 比泽尔(德国） |
12 | Vacuum pump 冷冻干燥机真空泵 | BAOSI |
13 | PLC 冷冻干燥机可编程控制器 | Omron |
14 | Electricity - total electrical load 冷冻干燥机总装机功率 | 71kW (380V, 50Hz, 3Phase, 5Wire) |
